Working with COMBO BOXES [Form Controls]
This blog post demonstrates how to create, populate and change comboboxes (form control) programmatically.
Form controls are not as flexible as ActiveX controls but are compatible with earlier versions of Excel. You can find the controls on the developer tab.
Table of Contents
- Create a combobox using vba
- Assign a macro -Â Change event
- Add values to a combobox
- Remove values from a combo box
- Set the default value in a combo box
- Read selected value
- Link selected value
- Change combobox properties
- Populate combox with values from a dynamic named range
- Populate combox with values from a table
- Currently selected combobox
Watch this video about Combo Boxes
Create a combobox using vba
Sub CreateFormControl()
'Worksheets("Sheet1").DropDowns.Add(Left, Top, Width, Height)
Worksheets("Sheet1").DropDowns.Add(0, 0, 100, 15).Name = "Combo Box 1"
End Sub
Recommended article
Recommended articles
In this post I am going to demonstrate two things: How to populate a combobox based on column headers from […]
Assign a macro - Change event
You can assign a macro to a combobox by press with right mouse button oning on the combobox and select "Assign Macro". Select a macro in the list and press ok!
This subroutine does the same thing, it assigns a macro named "Macro1" to "Combo box 1" on sheet 1. Macro1 is rund as soon as the selected value in the combo box is changed.
Sub AssignMacro()
Worksheets("Sheet1").Shapes("Combo Box 1").OnAction = "Macro1"
End Sub
Recommended article
Recommended articles
This article demonstrates how to run a VBA macro using a Drop Down list. The Drop Down list contains two […]
Add values to a combo box
You can add an array of values to a combo box. The list method sets the text entries in a combo box, as an array of strings.
Sub PopulateCombobox1()
Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat.List = _
Worksheets("Sheet1").Range("E1:E3").Value
End Sub
The difference with the ListFillRange property is that the combo box is automatically updated as soon as a value changes in the assigned range. You don´t need to use events or named ranges to automatically refresh the combo box, except if the cell range also changes in size.
Sub PopulateCombobox2()
Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat.ListFillRange = _
"A1:A3"
End Sub
You can also add values one by one.
Sub PopulateCombobox3()
With Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat
.AddItem "Sun"
.AddItem "Moon"
.AddItem "Stars"
End Sub
Recommended article
Recommended articles
A drop-down list in Excel prevents a user from entering an invalid value in a cell. Entering a value that […]
Remove values from a combo box
RemoveAllItems is self-explanatory.
Sub RemoveAllItems()
Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat.RemoveAllItems
End Sub
The RemoveItem method removes a value using a index number.
Sub RemoveItem()
Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat.RemoveItem 1
End Sub
The first value in the array is removed.
Recommended article
Recommended articles
A dialog box is an excellent alternative to a userform, they are built-in to VBA and can save you time […]
Set the default value in a combo box
The ListIndex property sets the currently selected item using an index number. ListIndex = 1 sets the first value in the array.
Sub ChangeSelectedValue()
With Worksheets("Sheet1").Shapes("Combo Box 1")
.List = Array("Apples", "Androids", "Windows")
.ListIndex = 1
End With
End Sub
Recommended article
Recommended articles
In this tutorial I am going to explain how to: Create a combo box (form control) Filter unique values and […]
Read selected value
The ListIndex property can also return the index number of the currently selected item. The list method can also return a value from an array of values, in a combo box. List and Listindex combined returns the selected value.
Sub SelectedValue()
With Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat
MsgBox "ListIndex: " & .ListIndex & vbnewline & "List value:" .List(.ListIndex)
End With
End Sub
Recommended article
Recommended articles
There are two different kinds of text boxes, Form controls and ActiveX Controls. Form controls can only be used on […]
Link selected value
Cell F1 returns the index number of the selected value in combo box 1.
Sub LinkCell()
Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat.LinkedCell = "F1"
End Sub
Cell G1 returns the selected value in combo box 1.
Sub LinkCell2()
With Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat
Worksheets("Sheet1").Range("G1").Value = .List(.ListIndex)
End With
End Sub
Recommended article
Recommended articles
There are two different kinds of text boxes, Form controls and ActiveX Controls. Form controls can only be used on […]
Change combobox properties
Change the number of combo box drop down lines.
Sub ChangeProperties()
Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat.DropDownLines = 2
End Sub
Populate combox with values from a dynamic named range
I created a dynamic named range Rng, the above picture shows how.
Sub PopulateFromDynamicNamedRange()
Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat.ListFillRange = "Rng"
End Sub
You can do the same thing as the subroutine accomplishes by press with right mouse button oning the combo box and then press with left mouse button on "Format Control...". Input Range: Rng
Back to top
Populate combox with values from a table
Sub PopulateFromTable()
Worksheets("Sheet1").Shapes("Combo Box 1").ControlFormat.List = _
[Table1[DESC]]
End Sub
Currently selected combobox
It is quite useful to know which combo box the user is currently working with. The subroutine below is assigned to Combo Box 1 and is rund when a value is selected. Application.Caller returns the name of the current combo box.
Sub CurrentCombo() MsgBox Application.Caller End Sub
